760GM-P23 MSI Socket AM3+ AMD 760G + SB710 Chipset AMD Phenom II X6/ II X4/ II X3/ II X2/ AMD Athlon II X4/ II X3/ AMD Sempron Processors Support DDR3 2x DIMM 6x SATA 3.0Gb/s Micro-ATX Motherboard (Refurbished)
Mfg Part No:
Global Part Number (GPN):
760GM-P23
Global Part Number (GPN):
1490883272
Looking for a large quantity of 760GM-P23? Call us at (800) 821-3354 or Request a Quote below and one of our sales representative will get in touch with you very soon.
Technical Specifications for 760GM-P23
| Model | |
| Manufacturer | MSI |
| Manufacturer Part # | 760GM-P23 |
| Performance | |
| Product Type | System Board |
| Form Factor | Micro ATX |
| CPU Socket Type | Socket AM3+ |
| Supported CPU(s) |
AMD Athlon II Processor AMD Phenom II Processor AMD Sempron Processor |
| Chipset | AMD 760G |
| South Bridge Chipset | AMD SB710 |
| Number of Memory Slot(s) | 2 |
| Number of Memory Channel(s) | 2 |
| Supported Memory Standard(s) |
PC3-10600 (DDR3-1333) PC3-6400 (DDR3-800) PC3-8500 (DDR3-1066) |
| Maximum Installed Memory | 16 GB |
| Expansion Slots |
PCI PCI-E 2.0 x16 PCI-E x1 |
| Storage Controller | SATA 3.0 Gbps |
| On-Board Video Controller | ATI Radeon 3000 Graphics |
| Audio Controller | Realtek ALC887 |
| Network | Gigabit Ethernet |
| Connectors/Ports |
24-pin ATX Power Connector Audio-In Audio-Out DVI-D Microphone PS/2 Keyboard PS/2 Mouse RJ-45 USB 2.0 VGA |
Request for Quote: 760GM-P23
Please call at (800) 821-3354 and one of our representative will be happy to assist you with part no 760GM-P23. Or Request a Quote below:
