Looking for a large quantity of E3-1501Mv6? Call us at (800) 821-3354 or Request a Quote below and one of our sales representative will get in touch with you very soon.
| Processor - Package Model: E3-1501M v6 Socket Type: BGA1440 | |
| Brand | Intel |
| Part No. | E3-1501Mv6 |
| Processor Type | Embedded |
| Processor Family | E3-1500 v6 |
| Series | Xeon E Processor |
| Core Model Type/ProcNo. | E3-1501M v6 |
| Processor Code Name | Kaby Lake |
| Core Stepping | B0 |
| Manufacturing Technology | 14 nm |
| # of Cores | 4 |
| # of Threads | 4 |
| Clock Speed | 2.90 GHz |
| L3 Cache Size | 6 MB |
| Max Memory Size | 64 GB |
| Memory Types | DDR4-2400 |
| Maximum Memory Speed | 2400 MHz |
| Memory Channels | 2 |
| Maximum Memory Bandwidth | 34.1 GB/s |
| ECC Memory Supported | Yes |
| CPU Socket Type | BGA1440 |
| Max CPU Configuration | 1 |
| TJUNCTION | 100 °C |
| Package Size | 42mm x 28mm |
| Processor Graphics | Intel HD Graphics P630 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.00 GHz |
| Graphics Video Max Memory | 1.7 GB |
| Graphics Output | eDP/DP/HDMI/DVI |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI) | 4096 x 2304 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 4096 x 2304 @ 60Hz |
| DirectX Support | 12 |
| OpenGL Support | 4.4 |
| Intel Quick Sync Video | Yes |
| Intel InTru 3D Technology | Yes |
| Intel Flexible Display Interface (Intel FDI) | Yes |
| Intel Clear Video HD Technology | Yes |
| # of Displays Supported | 3 |
| Device ID | 0x591D |
| Embedded Options Available | Yes |
| PCI Express | 3.0 |
| PCI Express Configurations |
1 x16 1x8+2x4 2 x8 |
| Max # of PCI Express Lanes | 16 |
| Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Identity Protection Technology Intel Speed Shift Technology Intel Transactional Synchronization Extensions Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Intel VT-x with Extended Page Tables (EPT) Thermal Monitoring Technologies |
| Instruction Set Extensions | Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
| Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel Memory Protection Extensions (Intel MPX) Intel OS Guard Intel Software Guard Extensions (Intel SGX) Secure Key |
| Product Condition | OEM |
| Standard Warranty | 21 days |
Please call at (800) 821-3354 and one of our representative will be happy to assist you with part no E3-1501Mv6. Or Request a Quote below:
