P55M-UD4 Gigabyte Socket LGA 1156 Intel P55 Express Chipset Core i7 / i5 / i3 Processors Support DDR3 4x DIMM 5x SATA 3.0Gb/s Micro-ATX Motherboard (Refurbished)

Mfg Part No:

P55M-UD4

Global Part Number (GPN):

1455244074

$407.66 $905.92 You Save: $498.26 (55% Spring Discount)

Availability:In Stock

Order with Confidence

Need to confirm compatibility or quantity? Our team is here to help.

1-800-821-3354 | [email protected] | Live Chat

Supporting IT Teams Since 1986

Quantity

Looking for a large quantity of P55M-UD4? Call us at (800) 821-3354 or Request a Quote below and one of our sales representative will get in touch with you very soon.

View Related Accessories Upgrade

Technical Specifications for P55M-UD4

Model
Manufacturer	Gigabyte Tech
Manufacturer Part #	P55M-UD4
Performance
Product Type	System Board
Form Factor	Micro ATX
CPU Socket Type	LGA 1156
Supported CPU(s)	Intel Core i3 Processor Intel Core i5 Processor Intel Core i7 Processor
Chipset	Intel P55 Express
Number of Memory Slot(s)	4
Number of Memory Channel(s)	2
Supported Memory Standard(s)	PC3-10600 (DDR3-1333) PC3-12800 (DDR3-1600) PC3-6400 (DDR3-800) PC3-8500 (DDR3-1066)
Maximum Installed Memory	16GB
Expansion Slots	PCI-E x16 PCI-E x4
Expansion Slots Details	1 x PCI Express x16 slot, running at x16 (PCIEX16) 1 x PCI Express x16 slot, running at x8 (PCIEX8) (The PCIEX16 and PCIEX8 slots conform to PCI Express 2.0 standard.) 1 x PCI Express x4 slot 1 x PCI slot
Storage Controller	SATA 3.0 Gbps
Storage Controller Details	Intel P55 Express Chipset 5 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4) supporting up to 5 SATA 3Gb/s devices 1 x eSATA 3Gb/s connector (eSATA/USB Combo) on the back panel supporting up to 1 SATA 3Gb/s device Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 GIGABYTE SATA2 chip 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, and JBOD
Network	Ethernet
Connectors/Ports	24-pin ATX Power Connector 8-pin 12V Power Connector Audio-In Audio-Out Chassis Fan Connector COM CPU Fan Connector PS/2 PS/2 Keyboard PS/2 Mouse RJ-45 Serial TPM Header USB 1.1 USB 2.0
Connectors/Ports Details	Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 7 x SATA 3Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x IEEE 1394a header 1 x power button 1 x clearing CMOS button 1 x reset button Back I/O Connectors 1 x PS/2 keyboard or PS/2 mouse port 1 x coaxial S/PDIF Out connector 1 x optical S/PDIF Out connector 9 x USB 2.0/1.1 ports 1 x eSATA/USB Combo connector 1 x IEEE 1394a port 1 x RJ-45 port 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line Out/Microphone)
Other Information
Features	Support for BIOS Support for Q-Flash Support for Xpress BIOS Rescue Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune Support for Dynamic Energy Saver 2 Support for Smart 6 Support for Q-Share

Request for Quote: P55M-UD4

Please call at (800) 821-3354 and one of our representative will be happy to assist you with part no P55M-UD4. Or Request a Quote below:

Quantity

How soon you need it?

General Information

P55M-UD4 Gigabyte Socket LGA 1156 Intel P55 Express Chipset Core i7 / i5 / i3 Processors Support DDR3 4x DIMM 5x SATA 3.0Gb/s Micro-ATX Motherboard (Refurbished)
