FOXG41MS Foxconn G41M-S Socket LGA775 Intel G41/ICH7 Chipset micro-ATX System Board (Motherboard) (Refurbished)
FOXG41MS Foxconn G41M-S Socket LGA775 Intel G41/ICH7 Chipset micro-ATX System Board (Motherboard) (Refurbished)

FOXG41MS Foxconn G41M-S Socket LGA775 Intel G41/ICH7 Chipset micro-ATX System Board (Motherboard) (Refurbished)

Mfg Part No:

FOXG41MS

Icon Global Part Number (GPN):

1472728403

$198.56 $441.25 You Save: $242.69 (55% Spring Discount)
Availability:In Stock
Order with Confidence

Need to confirm compatibility or quantity? Our team is here to help.

1-800-821-3354 | [email protected] | Live Chat

Supporting IT Teams Since 1986

Looking for a large quantity of FOXG41MS? Call us at (800) 821-3354 or Request a Quote below and one of our sales representative will get in touch with you very soon.

Technical Specifications for FOXG41MS

Model
Manufacturer Foxconn
Manufacturer Part # FOXG41MS
Performance
Product Type System Board
Form Factor Micro ATX
CPU Socket Type LGA 775
Supported CPU(s) Intel Celeron Dual-Core Processor
 Intel Core2 Duo Desktop Processor
 Intel Core2 Extreme Processor
 Intel Core2 Quad Processor
 Intel Pentium Dual-Core Processor
Clock Speed (Maximum) 1333 MHz
Chipset Intel G41 Express
South Bridge Chipset Intel ICH7
Number of Memory Slot(s) 2
Number of Memory Channel(s) 2
Supported Memory Standard(s) PC2-4200 (DDR2-533)
 PC2-5300 (DDR2-667)
 PC2-6400 (DDR2-800)
 PC2-8600 (DDR2-1066)
Maximum Installed Memory 8 GB
Expansion Slots PCI-E x1
 PCI-E x16
Expansion Slots Details 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
Storage Controller SATA 3.0 Gbps
Audio Controller Realtek ALC662
Network Gigabit Ethernet
Connectors/Ports 24-pin ATX Power Connector
 Audio-In
 Chassis Fan Connector
 CPU Fan Connector
 Microphone
 PS/2 Keyboard
 PS/2 Mouse
 RJ-45
 Serial
 VGA
Connectors/Ports Details Connector
  • 4 x SATA2 3.0 Gb/s connectors (No support for RAID and Hot Plug functions)
  • 1 x ATA100 IDE connector (supports 2 x IDE devices)
  • 1 x Floppy connector
  • 1 x Print port header
  • CPU/Chassis FAN connector
  • 24 pin ATX power connector
  • 4 pin 12V power connector
  • Front panel audio connector
  • 2 x USB 2.0 headers (support 4 USB 2.0 ports)

    • Rear Panel I/O
  • 1 x PS/2 Mouse Port
  • 1 x PS/2 Keyboard Port
  • 1 x Serial Port: COM1
  • 1 x VGA Port
  • 4 x Ready-to-Use USB 2.0 Ports
  • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • HD Audio Jack: Line in / Front Speaker / Microphone
    		•
    Request for Quote:  FOXG41MS

    Please call at (800) 821-3354 and one of our representative will be happy to assist you with part no FOXG41MS. Or Request a Quote below:



    General Information

  • FOXG41MS Foxconn G41M-S Socket LGA775 Intel G41/ICH7 Chipset micro-ATX System Board (Motherboard) (Refurbished)
    • Special Sale & Discount with Free Ground Shipping
